Our state-of-the-art packaged DX rooftop air conditioning units provide quiet and efficient temperature control and are modified to be lifted by crane or forklift.
Model | Tonnage | Dimensions (H x W x L, in.) | Shipping Weight (lbs.) | Duct Size (in.) | Nominal CFM (CFM) | Minimum Circuit Ampacity (MCA) |
|---|---|---|---|---|---|---|
Voyager™ with Electric Heat | 25 | 70 x 102 x 176.4 | 4700 | 20 | 10000 | 101 A |
Voyager™ with Gas Heat | 25 | 61.25 x 96 x 131.5 | 3600 | 20 | 10000 | 58.65 A |
Voyager™ with Electric Heat | 35 | 86.25 x 100 x 228 | 7000 | 20 | 14000 | 180.1 A |
Voyager™ with Electric Heat | 50 | 93.25 x 100 x 282 | 8300 | 20 | 20000 | 240.5 A |
High Static Voyager™ with Electric Heat | 35 | 86.3 x 100 x 211.4 | 7000 | 20 | 7000 | 179.8 A |
High Static Voyager™ with Electric Heat | 50 | 93.34 x 100 x 265 | 8300 | 20 | 10000 | 240.5 A |
Industrial High Static DX | 80 | 100 x 88 x 156 | 9800 | 20 | 12800 | 329 A |
TEMP-PRC001*-EN
Our vertical units have been specially designed to meet the specific needs associated with heating and cooling a special event.
Model | Tonnage | Dimensions (H x W x L, in.) | Weight (lbs) | Nominal Airflow (cfm) | Duct Size (in.) |
|---|---|---|---|---|---|
10 ton Vertical Unit | 10 | 83 x 36 x 62 | 1345 | 4000 | 12 |
10 ton Vertical Unit w/ supply and return duct connectors | 10 | 86 x 47 x 62 | 1415 | 4000 | 12 |
20 ton Vertical Unit | 20 | 96 x 36 x 91 | 2105 | 8000 | 20 |
20 ton Vertical Unit w/ supply and return duct connectors | 20 | 108 x 47 x 91 | 2245 | 8000 | 20 |
SRV-SVX05*-EN
Portable AC units can do more than just cool–they can also dry wet areas and protect equipment from water and humidity.
Trane Rental Services has an impressive array of heating, cooling, and power generation equipment. Our capabilities include 1- to 1,000-ton units of cooling, 36 kW to 1.5 MW of power generation, electric and indirect fired heaters up to 512,000 Btus.
