- Integrated ATS with supercapacitor — In the event of power loss, switchover to backup power is seamless and immediate.
- 25-micron filtration — Compared to larger-size filters, 25-micron filtration better ensures efficient heat transfer, protects components from wear and clogging, and extends equipment life.
- >2.75 bar head pressure — Enables longer runs between the CDU and racks.
- Dual VSD pumps — Respond dynamically to changes in cooling demand, resulting in higher energy efficiency and lower costs.
- Up to 1,350 kW cooling capacity — Meets demands of high-density racks.
- 316 stainless steel plate heat exchanger — Compatible with a variety of coolant fluids, high-grade stainless steel resists corrosion to ensure efficient heat transfer and high performance.
- Maximum flow rate of 1,500 liters per minute — Ensures that heat is quickly absorbed and transferred away from your servers.
- 900 mm footprint — with front and back panel access.
TCDU
Trane CDU - Coolant Distribution Unit
TCDU
Trane CDU - Coolant Distribution Unit
The most capacity of any coolant distribution unit of its size.
Powerful direct-to-chip liquid cooling is now available in a compact 900 mm footprint.
- Integrated ATS with supercapacitor
- 25-micron filtration
- Up to 1,350 kW cooling capacity in compact 900 mm footprint
- Front and back access
-
Powerful direct-to-chip cooling capacity
Engineered for high-density data centers, supporting IT equipment with a power consumption of up to 1.35 MW.
-
Space-saving, rack-based design
Rack-based form factor with no side access required so units can be installed tightly side-by-side. Ideal for retrofit data centers that need to maximize white space while providing high-capacity direct-to-chip cooling.
-
World-class service and support
Choosing Trane CDU liquid cooling gives you access to expert resources and support from Trane no matter where your operations are located. You’ll be supported by a team of data-center-qualified technicians who understand the unique challenges of your industry.
