Minimod™ / Model TACW
Thermafit™ Magnetic Bearing Modular Chiller
Minimod™ / Model TACW
Thermafit™ Magnetic Bearing Modular Chiller
Small footprint. Big performance.
- 60-135T/unit (1000T Bank), Expandable up to 10 modules
- Provides cooling only
- Available with R-134a refrigerant with options for low GWP R-513A
- Full load efficiency exceeds ASHRAE® 90.1 for cooling
- Available with knockdown construction
- Cleanable shell and tube heat-exchanger
- Zero oil-related maintenance
- Isolation valves on all serviceable parts
- Dedicated compressors for each refrigerant circuit avoid systems shut down
- Smallest modular footprint with cleanable shell and tube heat exchanger
- Driven by an ultra-quiet oil free compressor
Why Choose Thermafit Modular Units
Easily meet space requirements
Due to its small size, the TACW installs in very small spaces and facilitates convenient curbside delivery. Fully assembled, it passes through a standard 36-inch doorways and rides on passenger elevators. Components can be taken apart fully or partially for rigging into places like cramped equipment rooms.
Drive down emissions while reducing utility costs
This unit may be small but it doesn't skimp on performance. Drive down emissions while reducing utility costs using low GWP refrigerants and high efficiency compressors with variable speed drives. Full load efficiency exceeds ASHRAE® 90.1 standards.
Attractive hipster girl learning at university library while enjoying favourite music via headphones, young female student reading book and preparing for exam with textbook enjoying playlist
Ultra-quiet
Driven by an ultra quiet oil free compressor TACW produces 75 DB of sound at 10 feet (about the same as a TV at normal volume). Moving mechanical parts never touch the housing or frame to create noise.
Other Products You Might be Interested In
-
Thermafit™ Water-Cooled Modular Chiller
[Model MWC] At a glance
- 15-80 tons (800 ton bank) Model MWC standard efficiency
- Provides cooling
- Heat recovery option available
- Available with Low GWP R-454B Refrigerant
- Meets ASHRAE 90.1 for cooling
- Available with standard or high efficiency
- Variable speed compressor
- Single or dual circuit available
-
Thermafit™ Water-to-Water Modular Heat Piump
[Model WXM] At a glance
- 20-80 tons (800T Bank)
- Provides all electric heating or cooling
- Available with Low GWP R-454B Refrigerant
- Meets ASHRAE 90.1
- Ideal for cooler geographic regions with heating and cooling needs
-
Thermafit™ Water-Source Multi-pipe Modular Unit
[Model MWS] At a glance
- 30-60T (60-480T banks) 450 MBH to 7,200 MBH
- Provides all electric simultaneous heating and cooling
- Available with Low GWP R-454B Refrigerant
- Meets ASHRAE 90.1 cooling
- While in simultaneous mode, combined heating and cooling efficiencies up to 28 EER can be achieved
- 6-pipe design features three independent water loops
- Ideal for geothermal applications.
- 30-60T (60-480T banks) 450 MBH to 7,200 MBH
-
Thermafit™ Air-Cooled Modular Chiller
[Model AMC] At a glance
- 15-80 ton / unit
- Provides cooling
- Full heat recovery option available
- Integrated free cooling available
- Available with standard or high efficiency
- Available with Low GWP R-454B Refrigerant
- Meets ASHRAE 90.1
- Variable speed compressor and variable speed fans
-
Thermafit™ Air-to-Water Modular Heat Pump
[Model AMX] At a glance
- Each module capable of 30 tons cooling, 390 MBh heating
- Provides electric heating or cooling
- Available with Low GWP R-454B Refrigerant
- Meets ASHRAE 90.1
- Vapor injection enables higher leaving water termperature
- Lab tested to provide reliable heating in outdoor temperatures down to 0° F
