Axiom™ Horizontal and Vertical Water Source Heat Pumps
Axiom™ Horizontal and Vertical Water Source Heat Pumps
Standard Efficiency, High Efficiency & Variable Speed Models
Key Features:
- Outstanding energy efficiency, up to 40 EER
- Superior comfort
- Low life cycle costs
- Small, space saving footprint
- Choose from standard, high-efficiency and variable speed models
Lower Operating Costs
- All-electric solution with super-efficient full load EER and COP performance across three efficiency tiers: standard, high and dual stage
- Higher energy efficiency performance and excellent climate control with ECM fan motors on all tiers
- Energy-conserving, heat-recovery capabilities that transfer heat from one area to another to meet individual zone requirements
- High-efficiency models qualify for utility rebates based on Center for Energy Efficiency (CEE) rating system
Superior Occupant Comfort
- Easily scaled to accommodate multiple zones of comfort control
- Standard and Deluxe Sound Packages offer super-quiet performance based on AHRI 260 testing
- Improved Indoor Environmental Quality (IEQ) with expanded filtration options for MERV 8 and MERV 13 filters
Simplified Service and Maintenance
- New front cabinet access for routine maintenance activities, and nearly all internal components including control box for new vertical redesigned models
- Cabinet design eliminates 92% of fasteners, with only one screw needed to remove access panel for new GEHV and EXHV models
- Removable fan wheel and motor using factory provided orifice ring device
- Improved captive plug connections for all wiring, with clear plug connections
Models
| Standard Efficiency | High Efficiency | Variable Speed | ||
|---|---|---|---|---|---|
| Model | GEHV | GEHV | EXHV | DXHV | VSHV |
| Capacity | 0.5-5 Tons | 6-25 Tons | 0.75-6 Tons | 2-6 Tons | 2-5 Tons |
| Compressor | Single stage with ECM | Dual compressor with belt drive | Single stage with ECM | eStage™ 2-stage with ECM | eFlex™ variable speed with ECM |
| Configuration | Horizontal & Vertical | Horizontal (6-15 T) & Vertical (6-25 T) | Horizontal & Vertical | Horizontal & Vertical | Horizontal & Vertical |
| Unit Controller | Deluxe 24V or UC400/B | Deluxe 24V or UC400 | Deluxe 24V or UC400/B | Deluxe 24V or UC400/B | UC400 |
| Refrigerant | R410A | R410A | R410A | R410A | R410A |
| Warranty | 1 Year Parts 5 Years Compressor | 1 Year Parts 5 Years Compressor | 1 Year Parts 5 Years Compressor | 1 Year Parts 5 Years Compressor | 1 Year Parts 5 Years Compressor |
